Magicyle Ocelot Pro Step-Thru
$1,499.00
-
The Magicycle Ocelot Pro is a powerful, long-range step-thru electric bike designed for comfort and versatility across various terrains.
The Magicycle Ocelot Pro is a versatile, long-range electric bike designed for riders seeking comfort, power, and adaptability. Its step-thru frame facilitates easy mounting and dismounting, making it suitable for a wide range of riders. Equipped with a robust 750W brushless gear motor (peaking at 1100W) and a high-capacity 52V 20Ah LG lithium battery, the Ocelot Pro offers an impressive range of up to 80 miles per charge. Whether navigating city streets or exploring off-road trails, this e-bike delivers a smooth and responsive ride.
Key Features
Powerful Motor: 750W brushless gear motor with a peak output of 1100W and 96Nm torque for effortless hill climbs and acceleration.
Long-Range Battery: 52V 20Ah LG lithium battery providing up to 80 miles of range on a single charge.
Hydraulic Disc Brakes: Tektro 180mm hydraulic disc brakes ensure responsive and reliable stopping power.
Color LCD Display: IPX6 water-resistant display with USB charging port, offering real-time riding data and customization options.
Puncture-Resistant Fat Tires: 20″ x 4″ Kenda fat tires provide stability and traction on various terrains.
Adjustable Front Suspension: Alloy hydraulic suspension front fork with lockout and adjustment features for a smooth ride.
Shimano 7-Speed Gear System: Allows for versatile riding across different terrains.
High Payload Capacity: Supports up to 350 lbs, accommodating a wide range of riders and cargo.
Technical Specifications
Battery: 52V 20Ah LG lithium battery.
Motor: 750W brushless gear motor (1100W peak).
Torque: 96Nm.
Range: Up to 80 miles per charge.
Top Speed: Up to 28 MPH with pedal assist.
Charging Time: 4–6 hours with a 3.0A fast smart charger.
Display: Color LCD with USB charging port.
Pedal Assist: 7 levels with 12-magnet cadence sensor.
Brakes: Tektro 180mm hydraulic disc brakes.
Tires: 20″ x 4″ Kenda puncture-resistant fat tires.
Frame Size: 20″ 6061 aluminum frame.
Weight: 73 lbs (33 kg).
Payload Capacity: Up to 350 lbs.
Recommended Rider Height: 4’10” – 6’2″.
| Brand | Magicycle |
|---|---|
| Battery | 52V 20Ah |
| Motor | 750W/1500W peak |
| Range | Up to 100 miles per charge |
| Payload Capacity | 450 lbs |
| Brakes | Hydraulic |
| Top Speed | 28 mph |
| High-Power Motor | 750W/1500W peak |
| Package Dimension | 61" x 14" x 35" |
| Display | Color LCD Display with USB Charging |
| Frame size | 20" |
| Charger | Short-circuit proof 3.0A fast smart charger |
| Controller | 52V 750W FOC smart controller, Current Range 20~25 Amps (IPX8) |
| Recommended Rider Heights | 4'10" – 6'2" |
| Charging Time | 4 – 6 Hours |
| Weight | 73lbs/33kg |
| Pedal Assist | Intelligent 7 levels pedal assist with 12 magnet cadence sensor |
| Tire Size | 20"x4.0" |
| Tire Type | Fat Tires |
| Brake Lever | Aluminum alloy comfort grip levers with motor cutoff switch |
| Lights | Integrated front and brake lights |
| Freewheel | Shimano-14-28T BROWN/BK |
| Brake | 180mm Hydraulic Disc Brakes |
| Front Light | 6V LED light |
| Saddle | Super Soft Cushion |
| Seat Post | Diameter 30.9mm length 300mm |
| Kickstand | Heavy Duty Aluminum |
| Spokes | 13 Gauge on the Front / 12 Gauge on the Back |
| Front Fork | Alloy Hydraulic lockout suspension fork |
| Throttle | Half twist throttle |
| Pedal | Wellgo alloy pedal with reflectors |
| Frame | 20" 6061 Aluminum Frame |
| Chain | KMC chain |
| Stem | MA-400 SSABK |
| Crank | 48T, 170mm forged alloy, dual-sided bashguard |
| Gears | Shimano 7 speed gear shift system |
